Use Activity Monitor on your Mac

Activity Monitor shows the processes that are running on your Mac, so you can manage them and see how they affect your Mac's activity and performance.

This article describes some of the commonly used features of Activity Monitor, a kind of task manager that allows you see how apps and other processes are affecting your your CPU, memory, energy, disk, and network usage. Open Activity Monitor from the Utilities folder of your Applications folder, or use Spotlight to find it.

Overview

The processes shown in Activity Monitor can be user apps, system apps used by macOS, or invisible background processes. Use the five category tabs at the top of the Activity Monitor window to see how processes are affecting your Mac in each category.

Add or remove columns in each of these panes by choosing View > Columns from the menu bar. The View menu also allows you to choose which processes are shown in each pane:

  • All Processes
  • All Processes Hierarchically: Processes that belong to other processes, so you can see the parent/child relationship between them.
  • My Processes: Processes owned by your macOS user account.
  • System Processes: Processes owned by macOS.
  • Other User Processes: Processes that aren’t owned by the root user or current user.
  • Active Processes: Running processes that aren’t sleeping.
  • Inactive Processes: Running processes that are sleeping.
  • Windowed Processes: Processes that can create a window. These are usually apps.
  • Selected Processes: Processes that you selected in the Activity Monitor window.
  • Applications in the last 8 hours: Apps that were running processes in the last 8 hours.

CPU

The CPU pane shows how processes are affecting CPU (processor) activity:

CPU pane

Click the top of the “% CPU” column to sort by the percentage of CPU capability used by each process. This information and the information in the Energy pane can help identify processes that are affecting Mac performance, battery runtime, temperature, and fan activity.

More information is available at the bottom of the CPU pane:

  • System: The percentage of CPU capability currently used by system processes, which are processes that belong to macOS.
  • User: The percentage of CPU capability currently used by apps that you opened, or by the processes those apps opened.
  • Idle: The percentage of CPU capability not being used.
  • CPU Load: The percentage of CPU capability currently used by all System and User processes. The graph moves from right to left and updates at the intervals set in View > Update Frequency. The colour blue shows the percentage of total CPU capability currently used by user processes. The colour red shows the percentage of total CPU capability currently used by system processes.
  • Threads: The total number of threads used by all processes combined.
  • Processes: The total number of processes currently running.

You can also see CPU usage in a separate window or in the Dock:

  • To open a window showing current processor activity, choose Window > CPU Usage. To show a graph of this information in your Dock, choose View > Dock Icon > Show CPU Usage.
  • To open a window showing recent processor activity, choose Window > CPU History. To show a graph of this information in your Dock, choose View > Dock Icon > Show CPU History.

Memory

The Memory pane shows information about how memory is being used:

Memory pane

More information is available at the bottom of the Memory pane:

  • Memory Pressure: The Memory Pressure graph helps illustrate the availability of memory resources. The graph moves from right to left and updates at the intervals set in View > Update Frequency. The current state of memory resources is indicated by the colour at the right side of the graph:
    • Green: Memory resources are available.
    • Yellow: Memory resources are still available but are being tasked by memory-management processes, such as compression.
    • Red: Memory resources are depleted, and macOS is using your startup drive for memory. To make more RAM available, you can quit one or more apps or install more RAM. This is the most important indicator that your Mac may need more RAM.
  • Physical Memory: The amount of RAM installed in your Mac.
  • Memory Used: The total amount of memory currently used by all apps and macOS processes.
    • App Memory: The total amount of memory currently used by apps and their processes.
    • Wired Memory: Memory that can’t be compressed or paged out to your startup drive, so it must stay in RAM. The wired memory used by a process can’t be borrowed by other processes. The amount of wired memory used by an app is determined by the app’s programmer.
    • Compressed: The amount of memory in RAM that is compressed to make more RAM memory available to other processes. Look in the Compressed Mem column to see the amount of memory compressed for each process.
  • Swap Used: The space used on your startup drive by macOS memory management. It’s normal to see some activity here. As long as memory pressure is not in the red state, macOS has memory resources available.
  • Cached Files: Memory that was recently used by apps and is now available for use by other apps. For example, if you’ve been using Mail and then quit Mail, the RAM that Mail was using becomes part of the memory used by cached files, which then becomes available to other apps. If you open Mail again before its cached-files memory is used (overwritten) by another app, Mail opens more quickly because that memory is quickly converted back to app memory without having to load its contents from your startup drive.

Energy

The Energy pane shows overall energy use and the energy used by each app:

  • Energy Impact: A relative measure of the current energy consumption of the app. Lower numbers are better. A triangle to the left of an app’s name means that the app consists of multiple processes. Click the triangle to see details about each process.
  • Avg Energy Impact: The average energy impact for the past 8 hours or since the Mac started up, whichever is shorter. Average energy impact is also shown for apps that were running during that time, but have since been quit. The names of those apps are dimmed.
  • App Nap: Apps that support App Nap consume very little energy when they are open but not being used. For example, an app might nap when it’s hidden behind other windows, or when it’s open in a space that you aren’t currently viewing.
  • Preventing Sleep: Indicates whether the app is preventing your Mac from going to sleep.

Energy pane

More information is available at the bottom of the Energy pane:

  • Energy Impact: A relative measure of the total energy used by all apps. The graph moves from right to left and updates at the intervals set in View > Update Frequency.
  • Graphics Card: The type of graphics card currently used. Higher–performance cards use more energy. Macs that support automatic graphics switching save power by using integrated graphics. They switch to a higher-performance graphics chip only when an app needs it. “Integrated” means the Mac is currently using integrated graphics. “High Perf.” means the Mac is currently using high-performance graphics. To identify apps that are using high-performance graphics, look for apps that show “Yes” in the Requires High Perf GPU column.
  • Remaining Charge: The percentage of charge remaining on the battery of a portable Mac.
  • Time Until Full: The amount of time your portable Mac must be plugged into an AC power outlet to become fully charged.
  • Time on AC: The time elapsed since your portable Mac was plugged into an AC power outlet.
  • Time Remaining: The estimated amount of battery time remaining on your portable Mac.
  • Time on Battery: The time elapsed since your portable Mac was unplugged from AC power.
  • Battery (Last 12 hours): The battery charge level of your portable Mac over the last 12 hours. The colour green shows times when the Mac was getting power from a power adapter.

As energy use increases, the length of time that a Mac can operate on battery power decreases. If the battery life of your portable Mac is shorter than usual, you can use the Avg Energy Impact column to find apps that have been using the most energy recently. Quit those apps if you don’t need them, or contact the developer of the app if you notice that the app’s energy use remains high even when the app doesn’t appear to be doing anything.


Disk

The Disk pane shows the amount of data that each process has read from your disk and written to your disk. It also shows “reads in” and “writes out” (IO), which is the number of times that your Mac accesses the disk to read and write data.

Disk pane

The information at the bottom of the Disk pane shows total disk activity across all processes. The graph moves from right to left and updates at the intervals set in View > Update Frequency. The graph also includes a pop-up menu to switch between showing IO or data as a unit of measurement. The colour blue shows either the number of reads per second or the amount of data read per second. The colour red shows either the number of writes out per second or the amount of data written per second.

To show a graph of disk activity in your Dock, choose View > Dock Icon > Show Disk Activity.


Network

The Network pane shows how much data your Mac is sending or receiving over your network. Use this information to identify which processes are sending or receiving the most data.

 Network tab

The information at the bottom of the Network pane shows total network activity across all apps. The graph moves from right to left and updates at the intervals set in View > Update Frequency. The graph also includes a pop-up menu to switch between showing packets or data as a unit of measurement. The colour blue shows either the number of packets received per second or the amount of data received per second. The colour red shows either the number of packets sent per second or the amount of data sent per second.

To show a graph of network usage in your Dock, choose View > Dock Icon > Show Network Usage.


Learn more

  • For more information about Activity Monitor, open Activity Monitor and choose Help > Activity Monitor. You can also see a short description of many items in the Activity Monitor window by hovering the mouse pointer over the item.
  • Learn about kernel task and why Activity Monitor might show that it’s using a large percentage of your CPU.
